The Flat Hanger



TFH-30x30-WW-24V-DIM

The Flat Hanger by VOLTRON® is a high-quality LED panel with a uniform light distribution for intensive use for ceiling systems.The frame (C-profile) is completely in ALU and provides extra strength.ALU plate ensures an optimal cooling and a long lifespan of light output.The Flat Hanger can also be suspended floating using optional iron cable set or ceiling/wall mounting using optional suspension bracket (BP-PLAFOND) or mounting frame (TFH-BOX).The device is dimmable as standard (0-10VDC, PWM, resistor, DALI) - by means of a power supply (constant voltage), the LED power supply can be ordered separately. TYPE TFH 30x30 WW : 300x300mm - 42W - 2700K - 700Lm - MacAdam 3 - L80 >50.000h - thickness = 12mm - IP52 class.Always 5 years warranty.


Lichtkleur
2700K
Wattage
11W
Lumen
700Lm
IPwaarde
52
Voltage
24V
Dimbaar
Yes
CRI
>85
UGR
<19
MacAdam
3
LB
L80 >50.000
IK
03
Lengte
30CM
Breedte
30CM
Dikte
1,2CM
Spreidingshoek
120°
DriverIngesloten
No
garantie
5

All product specifications for : TFH-30x30-WW-24V-DIM


Productnumber
TFH-30x30-WW-24V-DIM
Barcode
LH-1139
Light color (CCT)
2700K
IP value
52
Led Chip
SMD2835
Number of led
56
Voltage
24V
Wattage
11W
Length
30CM
Width
30CM
Thickness
1,2CM
Finish color
White
CRI
>85
Lxx @Ta = 25°C
L80 >50.000
UGR
<19
MacAdam
3
IK
03
Spread angle
120°
Lumen
700Lm
Dimmable
Yes
Driver included
No
Cable length
200CM
Constant voltage
Yes
Packed per
1

Specification text with product code

Type : The Flat Hanger / productnumber : TFH-30x30-WW-24V-DIM
Closed individual professional 'ultra thin' square LED panel for suspended ceilings. The housing has a slot on the rear for floating suspension by means of. optional iron cable set or ceiling / wall mount using optional suspension bracket. A white ALU housing with narrow edge and mitred corners. The housing is provided on the visible side with a groove for aesthetic mounting on suspended ceilings. Provided with high-quality ALU plate at the rear to promote the firmness and accelerated cooling of the LEDs. The frame is made entirely of aluminum, with a special C-profile for higher stability and strength. Equipped with anti-fall protection. With a separately built-in Mitsubishi diffuser (better evenness). The panel has 56leds type Epistar SMD2835. Light control via opaque opal optic from PC for glare protection and maximum luminaire efficiency. Panel is dimmable if applicable. Dimensions 30x30 cm (LxW), thickness 1.2 cm. Generates 11W and 700lm at 24V and a light color 2700K (white). IP52 class. Extremely suitable for office spaces, meeting rooms, showrooms, shops, corridors and classrooms. Can be connected to Meanwell power supplies (IP67) with a constant voltage. With a color rendering index of> 85. Equipped with photo metric report and IES file for elaboration in DIALux. L80> 50,000 @ Ta = 25 ° C Merk = Voltron®, producttype : The Flat Hanger, bestelcode=TFH-30x30-WW-24V-DIM


Specification text without product code

Closed individual professional 'ultra thin' square LED panel for suspended ceilings. The housing has a slot on the rear for floating suspension by means of. optional iron cable set or ceiling / wall mount using optional suspension bracket. A white ALU housing with narrow edge and mitred corners. The housing is provided on the visible side with a groove for aesthetic mounting on suspended ceilings. Provided with high-quality ALU plate at the rear to promote the firmness and accelerated cooling of the LEDs. The frame is made entirely of aluminum, with a special C-profile for higher stability and strength. Equipped with anti-fall protection. With a separately built-in Mitsubishi diffuser (better evenness). The panel has 56leds type Epistar SMD2835. Light control via opaque opal optic from PC for glare protection and maximum luminaire efficiency. Panel is dimmable if applicable. Dimensions 30x30 cm (LxW), thickness 1.2 cm. Generates 11W and 700lm at 24V and a light color 2700K (white). IP52 class. Extremely suitable for office spaces, meeting rooms, showrooms, shops, corridors and classrooms. Can be connected to Meanwell power supplies (IP67) with a constant voltage. With a color rendering index of> 85. Equipped with photo metric report and IES file for elaboration in DIALux. L80> 50,000 @ Ta = 25 ° C
Office spaces, meeting rooms
Showroom, shops
Corridors
Classrooms
Suspension possible with the optional iron cable set
Mounting on ceilings or walls with optional bracket
Mounting also with closed surface mounted box
